Year From 2011
Power 105 110 hp
displacement 1,.,2 TSI
Engine code CJZA, CJZB, CJZC, CJZD, CYVA, CYVB, CYVB, CYVD
2-year warranty
Turbo plug & play ’s performance ( )installation without modification
Stage 2
Oversized high-flow MFS* compressor wheel 39mm
Re-profiled compressor housing for Fits new wheel oversized
360° thrust bearing
High-speed balancing (150,000 RPM) on Cimat VSR bench.
Stage 2+
Oversized high-flow MFS* compressor wheel 43mm
Re-profiled compressor housing to accommodate an oversized new wheel
360° thrust bearing
High-speed balancing (150,000 RPM) on Cimat VSR bench.
MFS: Forged aluminium compressor wheel, lighter, larger and taller than the original, allowing d'to achieve 15% additional compression.
For To achieve maximum power, you must also adjust your systems, d'injection, d'exhaust, cooling and engine ECU. The wastegate must be adjusted when remapping the ECU.
MFS: Forged aluminium compressor wheel, lighter, larger and taller than the original, providing d'an additional 15 per cent compression.
For To achieve maximum power, you must also adjust your injection systems, d' d'exhaust, cooling and engine ECU. The wastegate must be adjusted .
OEM Reference
04E145703Q, 04E145703QV, 04E145703QX, 04E145704LV, 04E145704LX, 04E145704N, 04E145704NV, 04E145704NX, 04E145704T, 04E145704TV, 04E145704TX, 04E145713B, 04E145713BV, 04E145713BX, 04E145713Q, 04E145713QV, 04E145713QX, 04E145721L, 04E145721LV, 04E145721LX
Manufacturer reference
030TC11001000, 030-TC-11001-000, F026510031,
Compatible vehicle
Audi
A3 1.2 TSI 105 hp from 2011
A3 1.2 TSI 110 hp from 2011
Seat
Leon 1.2 TSI 16V 110 hp from 2011
Skoda
Octavia 1.2 TSI 16V 110 hp from 2011
Volkswagen
Golf VII 1.2 TSI 105 hp from 2012
Golf VII 1.2 TSI 16V 110 hp from 2011
