Turbo Cartridge 3.0 TFSI TSI 286 330 340 354 449 455 461 462 hp, 06M145689M, 06M145689J, 06M145689A, 18539700164, 18539700025

  • Online only
  • New product
New
Turbo Cartridge 3.0 TFSI TSI 286 330 340 354 449 455 461 462 hp, 06M145689M, 06M145689J, 06M145689A, 18539700164, 18539700025
  • Turbo Cartridge 3.0 TFSI TSI 286 330 340 354 449 455 461 462 hp, 06M145689M, 06M145689J, 06M145689A, 18539700164, 18539700025
ACK-374T
Year: From May 2016, depending on the application; end date not specified
Power: 286, 330, 340, 354, 449, 455, 461 and 462 hp
displacement: 3.0
Engine code: CWGD, DLZA, CZSE, CZSA, EALD, DCBD, DCBE, MDC.BE, DLZB, MCX.TA
Warranty: 2 years
Turbo Complete Gasket Set (required for fitting the new turbo)
Turbo Complete Gasket Set (required for fitting the new turbo)
18 €
€91.82 VAT included

76.52 tax excl.

Quantity
Delivered the next day (if ordered before 5 pm)

Description

This central cartridge Cartridge is designed for various engine variants: 3., 0 TFSI and TSI, with power outputs ranging from 286 to 462 hp. It enables the replacement of the turbocharger’s central assembly when the part numbers and fitment correspond to the original dfitment.

The documented applications cover several models Audi, Porsche and Volkswagen, in petrol or petrol/electric versions depending on the vehicle.

Turbo part numbers

OEM part numbers

PAB145689
PAC145689
9A714568900
06M145689M
06M145689J
06M145689AC
06M145689A

Manufacturer’s part numbers

1853-970-0025
1853-970-0070
1853-970-0102
1853-970-0164
1853-988-0164
18539700164
18539880164
18539700025
18539700070
18539700102
18539880025
18539880070
18539880102

Compatible vehicles and assignments

Audi
A4 B9 (8W2, 8WC) — 354 hp
3.0 TFSI/TSI • Essence • From 05/2016, end date unspecified
Engine code : CWGD
A4 B9 Front (8W5, 8WD) — 354 hp
3.0 TFSI/TSI • Essence • From May 2016, end date unspecified
Engine code : CWGD
A5 (F53, F5P) — 354 hp
3.0 TFSI/TSI • Essence • From July 2016, end date unspecified
Engine code : CWGD
A5 Convertible (F57, F5E) — 354 hp
3.0 TFSI/TSI • Essence • From March 2017, end date unspecified
Engine code : CWGD
A5 Sportback (F5A, F5F) — 354 hp
3.0 TFSI/TSI • Essence • From 09/2016, end date unspecified
Engine code : CWGD
A6 Allroad C8 (4AH) — 340 hp
3.0 TFSI/TSI • Essence/electric • From November 2019, end date unspecified
Engine code : DLZA
A6 C8 (4A2) — 340 hp
3.0 TFSI/TSI • Essence/electric • From 02/2018, end date unspecified
Engine code : DLZA
A6 C8 Avant (4A5) — 340 hp
3.0 TFSI/TSI • Essence/electric • From May 2018, end date unspecified
Engine code : DLZA
A7 Sportback (4KA) — 340 hp
3.0 TFSI/TSI • Essence/electric • From 10/2017, end date unspecified
Engine code : DLZA
A8 D5 (4N2, 4N8, 4NC, 4NL) — 286 hp
3.0 TFSI/TSI • Essence/electric • Since July 2018, end date unspecified
Engine code : CZSA
A8 D5 (4N2, 4N8, 4NC, 4NL) — 340 hp
3.0 TFSI/TSI • Essence/electric • From June 2017, end date unspecified
Engine code : CZSE
A8 D5 (4N2, 4N8, 4NC, 4NL) — 449 hp
3.0 TFSI/TSI • Essence/electric • Since October 2019, end date unspecified
Engine code : CZSE
A8 D5 (4N2, 4N8, 4NC, 4NL) — 462 hp
3.0 TFSI/TSI • Essence/electric • From Nov 2021, end date unspecified
Engine codes: CZSE, EALD
Q5 (FYB, FYG) — 354 hp
3.0 TFSI/TSI • Essence • From November 2016, end date unspecified
Engine code : CWGD
Q7 (4MB, 4MG) — 340 hp
3.0 TFSI/TSI • Essence/electric • Since July 2019, end date unspecified
Engine code : DCBD
Q7 (4MB, 4MG) — 455 hp
3.0 TFSI/TSI • Essence/electric • Since November 2019, end date unspecified
Engine code : DCBE
Q8 (4MN, 4MT) — 340 hp
3.0 TFSI/TSI • Essence/electric • Since February 2018, end date unspecified
Engine code : DCBD
Porsche
Cayenne (9YA) — 340 hp
3.0 TFSI/TSI • Essence • From May 2017, end date unspecified
Engine codes: DCBE, MDC.BE
Cayenne (9YA) — 462 hp
3.0 TFSI/TSI • Essence/electric • From 01/2019, end date unspecified
Engine codes: DCBE, MDC.BE
Cayenne Coupé (9YB) — 340 hp
3.0 TFSI/TSI • Essence • From 01/2019, end date unspecified
Engine code : DCBE
Cayenne Coupé (9YB) — 461 hp
3.0 TFSI/TSI • Essence/electric • From Jan 2019, end date unspecified
Engine code : DCBE
Macan (95B) — 354 hp
3.0 TFSI/TSI • Essence • Since May 2018, end date unspecified
Engine code : DLZB
Panamera (971) — 330 hp
3.0 TFSI/TSI • Essence • From May 2016, end date unspecified
Engine code : MCX.TA
Panamera Sport Turismo (971) — 330 hp
3.0 TFSI/TSI • Essence • Since May 2017, end date unspecified
Engine code : MCX.TA
Volkswagen
Touareg (CR7, RC8) — 340 hp
3.0 TFSI/TSI • Essence • Since March 2018, end date unspecified
Engine code : DCBE

Technical specifications

Product type: Central cartridge Cartridge Turbo
Engine: 3-.0- TFSI / TSI
Fuel: Essence or petrol/electric depending on the application
Documented power ratings: 286, 330, 340, 354, 449, 455, 461 and 462 hp
Engine codes: CWGD, DLZA, CZSE, CZSA, EALD, DCBD, DCBE, MDC.BE, DLZB, MCX.TA
Documented production periods: start dates between May 2016 and November 2021 depending on the application; end dates not specified

Fitting instructions

⚠️ WARNING — IMPORTANT BEFORE INSTALLATION

Before fitting the cartridge Cartridge, identify and rectify the cause of the previous failure. Check the lubrication circuit, the oil supply and return lines das well as the cleanliness of the pipes. Also check the inlet, ensure there are no foreign objects present, and check the condition of the housings containing the cartridge.

Carry out assembly and priming in accordance with the applicable recommendations, then follow the manufacturer’s instructions. A lubrication fault that is not rectified may lead to further failure of the turbocharger.

How do you identify the correct turbocharger?

Check the part number marked on the original turbocharger d, then compare the OEM and manufacturer part numbers.. Also check the make, model, generation, body style, engine type, power output at hp, the mountingYear and the engine code.. An identical engine type does not always guarantee compatibility.

⚠️ Check your turbo’s part numbers

Before ordering, compare the part number marked on your original turbo d with the part numbers listed in this data sheet. An identical engine specification does not always guarantee compatibility.

If in doubt, please contact us with the full part number of your original turbo dand your vehicle details.

Product Details
ACK-374T
3701803901958
New
Attachments
Download

Turbo: specialists in turbochargers since 2012

ALFI TURBO specialises in the sale of turbochargers for for cars, commercial vehicles, heavy goods vehicles, construction machinery, agricultural machinery and boats: new turbochargers, remanufactured units, hybrid turbochargers, Cartridge and turbocharger spare parts. Over 20,000 items are available.

Find the right turbocharger for your engine

The turbocharger plays a vital role in the operation and performance d of a turbocharged engine. When a turbocharger needs replacing, it is important d to identify the exact part number before ordering.

ALFI TURBO supplies turbochargers for for a wide range of makes and engine types: cars, commercial vehicles, heavy goods vehicles, construction machinery, tractors and agricultural machinery, as well as various marine applications.

You can search for your turbo based on the vehicle or application, engine type, engine code, or directly using d an OEM or manufacturer part number found on your old turbocharger.

Turbo new, remanufactured, hybrid and Cartridge

Turbo new

Browse our range of new turbochargers for for diesel and petrol engines. ALFI TURBO has over 5,500 new turbochargers in stock for covering a wide range of makes, engine types and turbocharger part numbers.

View new turbochargers →

Turbo as remanufactured units

A standard exchange turbo allows you to replace a turbocharger whilst returning the old part where a deposit is required. Our catalogue includes numerous part numbers for from various makes and engine types.

View standard exchange turbochargers →

Hybrid Turbo

Hybrid turbos are designed for set-ups requiring greater air flow d and higher performance potential than a standard set-up. Specifications depend on the turbo, its tuning and the engine configuration.

View hybrid turbos →

Cartridge turbo

The turbo Cartridge, also known as the central turbo cartridge, comprises the main rotating components of the turbocharger. ALFI TURBO has over 6,000 Cartridge for turbo part numbers.

View turbo Cartridge →

for turbochargers for a wide range of applications

Our catalogue covers a wide range of d applications fitted with d a turbocharged engine.

  • diesel and petrolcars;
  • commercial vehicles;
  • heavy goods vehicles and lorries;
  • construction and civil engineeringmachinery;
  • tractors and agricultural machinery;
  • boats and marine applications.

How do you identify the correct turbo part number?

A single engine type may have been fitted with several different turbochargers depending on theYear, power output, engine version or technical evolution.. The application alone is therefore not always sufficient for to accurately identify the correct turbo.

Before ordering, note down the part numbers shown on the identification plate d of your old turbocharger. This may be d an OEM part number or d a part number from the turbo manufacturer.

Compare these part numbers with those listed on our product pages.. If in doubt, our team can help you verify the part number you are looking for before you place your order.

Turbo failure: identify the cause before replacement

A loss of power, an unusual whistling noise, oil consumption d, abnormal smoke or poor engine performance may be linked to a turbocharger fault.

However, a fault that appears to be turbo-related may also stem d from a lubrication issue, d from contaminated oil, d from a foreign object, from the intake or exhaust systems, or d from another engine peripheral component.

It is therefore important to investigate the cause of the fault before fitting a new turbo or a new Cartridge.

→ Identifying the symptoms d of a turbo failure

→ Understand the main causes of turbo failure d
