Turbo Cartridge Dacia / 1 5 Blue 75 95 101 116 , 144102267R, 144106234R, 144106580R, 16359700039, 16359700058 Renault. dCi hp

  • Online only
  • New product
New
Turbo Cartridge Dacia / 1 5 Blue 75 95 101 116 , 144102267R, 144106234R, 144106580R, 16359700039, 16359700058 Renault. dCi hp
  • Turbo Cartridge Dacia / 1 5 Blue 75 95 101 116 , 144102267R, 144106234R, 144106580R, 16359700039, 16359700058 Renault. dCi hp
ACK-388T
Year: October 2017 to an unspecified date
Power: 75, 95, 101 and 116 hp
displacement: 1.5
Engine code: K9K 854, K9K 872, K9K 873, K9K 874, K9K 876, K9K 877, K9K 878
Warranty: 2 years
Kit Montage CHRA, vis M5x8 5pcs, M6x10 5pcs, Rondelle diamètre 6 5pcs
Kit Montage CHRA, vis M5x8 5pcs, M6x10 5pcs, Rondelle diamètre 6 5pcs
9.9 €
Turbo Complete Gasket Set (required for fitting the new turbo)
Turbo Complete Gasket Set (required for fitting the new turbo)
18 €
€80.16 VAT included

66.8 tax excl.

Quantity
Delivered the next day (if ordered before 5 pm)

Description

This central cartridge Cartridge is designed for use with several engine variants: 1., 5 Blue dCi with power outputs ranging from 75 to 116 hp, fitted to the following vehicles: Dacia and Renault. . It is used to replace the central rotating assembly of the turbocharger when the original part numbers dmatch.

The main documented applications include, in particular, the Dacia Duster and Lodgy as well as the Renault Clio V, Express, Kangoo III and Mégane IV. Compatibility must always be confirmed using the part number of the removed turbocharger.

Turbo part numbers

OEM part numbers

6080903700
6081402000
6081424100
144102267R
144106234R
144106580R

Manufacturer’s part numbers

16359700039
16359700058
16359880039
16359880058
16359980058

Compatible vehicles and assignments

Dacia

Duster (HM_) PC — 116 hp
Diesel 1.5 Blue dCi — 10/2017 to an unspecified end date
Engine codes: K9K 872, K9K 876
Duster (HM_) PC — 116 hp
Diesel 1.5 Blue dCi — 10/2017 to unspecified end date
Engine codes: K9K 874, K9K 878
Lodgy (JS_) PC — 95 hp
Diesel 1.5 Blue dCi — 08/2018 to unspecified end date
Engine codes: K9K 872, K9K 876

Renault

Clio V (B7_) PC — 101 hp
Diesel 1.5 Blue dCi — 11/2021 to unspecified end date
Engine codes: K9K 872, K9K 876
Express Box Body/MPV LCV — 75 hp
Diesel 1.5 Blue dCi — May 2021 to unspecified end date
Engine codes: K9K 872, K9K 876
Express Box Body/MPV LCV — 95 hp
Diesel 1.5 Blue dCi — 05/2021 to an unspecified end date
Engine codes: K9K 872, K9K 876
Grand Kangoo III MPV PC — 95 hp
Diesel 1.5 Blue dCi — 01/2024 to unspecified end date
Engine code : K9K 876
Kangoo III Box Body/MPV LCV — 75 hp
Diesel 1.5 Blue dCi — 06/2021 to unspecified end date
Engine code : K9K 876
Kangoo III Box Body/MPV LCV — 95 hp
Diesel 1.5 Blue dCi — 06/2021 to unspecified end date
Engine codes: K9K 876, K9K 877
Kangoo III Box Body/MPV LCV — 116 hp
Diesel 1.5 Blue dCi — 06/2021 to an unspecified end date
Engine codes: K9K 876, K9K 877
Kangoo III MPV PC — 75 hp
Diesel 1.5 Blue dCi — 07/2021 to unspecified end date
Engine code : K9K 876
Kangoo III MPV PC — 95 hp
Diesel 1.5 Blue dCi — 07/2021 to unspecified end date
Engine codes: K9K 876, K9K 877
Kangoo III MPV PC — 116 hp
Diesel 1.5 Blue dCi — 10/2021 to unspecified end date
Engine codes: K9K 876, K9K 877
Mégane IV Grandtour (K9A/M/N_) PC — 116 hp
Diesel 1.5 Blue dCi — 08/2018 to unspecified end date
Engine codes: K9K 872, K9K 873, K9K 876, K9K (reference truncated in the available data)
Mégane IV Hatchback (B9A/M/N_) PC — 95 hp
Diesel 1.5 Blue dCi — 08/2018 to unspecified enddate
Engine codes: K9K 872, K9K 854, K9K 876, K9K (reference truncated in the available data)
Mégane IV Hatchback (B9A/M/N_) PC — 116 hp
Diesel 1.5 Blue dCi — 08/2018 to unspecified end date
Engine codes: K9K 872, K9K 873, K9K 854, K9K (reference truncated in the available data)

Technical specifications

Product type: central cartridge Cartridge Turbo
Engine: 1.5 Blue dCi
Fuel: diesel
Power outputs: 75, 95, 101 and 116 hp
Documented engine codes: K9K 854, K9K 872, K9K 873, K9K 874, K9K 876, K9K 877, K9K 878
Documented production periods: from October 2017 onwards, depending on the application

Fitting instructions

⚠️ WARNING — IMPORTANT BEFORE INSTALLATION

Before fitting the Cartridge, identify and rectify the cause of the previous fault. Check the lubrication circuit, the supply and return lines d, then check that the pipes, inlet and sump are clean.. The sumps must be inspected and free from damage or foreign objects.. Carry out the assembly, adjustment and priming in accordance with the applicable recommendations and the manufacturer’s instructions. A lubrication fault that is not rectified may lead to the turbocharger failing again.

How do you identify the correct turbo?

Check the part number of the original turbo d as well as the OEM and manufacturer part numbers. Also check the make, model, generation, body style, engine type, power output at hp, production period and engine code. An identical engine may be fitted with several different turbo set-ups.

⚠️ Check your turbo’s part numbers

Before ordering, compare the part number marked on your original turbo d with the part numbers listed in this data sheet. An identical engine does not always guarantee compatibility.

If you are unsure about the identification of your turbocharger, please contact us with the part number found on your original turbocharger d.
