Turbo Cartridge 3.0 TDI 163 190 204 211 218 224 249 272 374 hp, 059145873CL, 059145873CH, 059145873BP, 059145873BJ, 059145873DB

  • Online only
  • New product
New
Turbo Cartridge 3.0 TDI 163 190 204 211 218 224 249 272 374 hp, 059145873CL, 059145873CH, 059145873BP, 059145873BJ, 059145873DB
  • Turbo Cartridge 3.0 TDI 163 190 204 211 218 224 249 272 374 hp, 059145873CL, 059145873CH, 059145873BP, 059145873BJ, 059145873DB
ACG-839
Year: May 2014 to an unspecified date
Power: 163, 190, 204, 211, 218, 224, 249, 272 and 374 hp
displacement: 3.0 TDI
Engine code: CRTC, CSWB, CRTF, CZVC, CRTE, CZVA, CRTD, CZVF, CTCB, CZVD, CTCC, CZVB, CZVE, CZZA, CZZB, CVMD, CVZA, DDXA, DDXB, DDXC, DDXD
Warranty: 2 years
Kit Montage CHRA, vis M5x8 5pcs, M6x10 5pcs, Rondelle diamètre 6 5pcs
Kit Montage CHRA, vis M5x8 5pcs, M6x10 5pcs, Rondelle diamètre 6 5pcs
9.9 €
Turbo Complete Gasket Set (required for fitting the new turbo)
Turbo Complete Gasket Set (required for fitting the new turbo)
18 €
€99.60 VAT included

83 tax excl.

Quantity
Next-day delivery (if ordered before 5 pm)

Description

This central cartridge Cartridge is designed for turbochargers fitted to various 3-series engines.0 TDI from 163 to 374 hp. It enables the central assembly of the turbocharger to be replaced when the part numbers d'correspond to the original'.

The applications documented include, in particular, the Audi A4, A5, A6, A7 and Q7, as well as the Volkswagen Amarok. The benchmark for turbochargers dThe origin must be verified before any order is placed.

Turbo part numbers

OEM part numbers

059145873CL
059145873CH
059145873BP
059145873BJ
059145873DB
059145873EN
059145873BL
059145873FA
059145873ES

Manufacturer’s part numbers

839077-0009
839077-2009
839077-5002S
839077-5008S
839077-5009S
839077-5011S
839077-9
839078-0001
839078-1
839078-2001
839078-5001S
881651-0001
881651-1
881651-5001S
888580-1
888580-2001
888580-5001S

Compatible vehicles and assignments

AUDI
A4 Allroad B9 (8WH, 8WJ) — 218 hp
Diesel, PC — January 2016 to August 2018
Engine code : CSWB
A4 Allroad B9 (8WH, 8WJ) — 272 hp
Diesel, PC — January 2016 to August 2018
Engine code : CRTC
A4 B9 (8W2, 8WC) — 218 hp
Diesel, PC — September 2015 to August 2018
Engine code : CSWB
A4 B9 (8W2, 8WC) — 272 hp
Diesel, PC — May 2015 to August 2018
Engine code : CRTC
A4 B9 Front (8W5, 8WD) — 218 hp
Diesel, PC — October 2015 to August 2018
Engine code : CSWB
A4 B9 Front (8W5, 8WD) — 218 hp
Diesel, PC — November 2015 to August 2018
Engine code : CSWB
A4 B9 Front (8W5, 8WD) — 272 hp
Diesel, PC — August 2015 to August 2018
Engine code : CRTC
A5 (F53, F5P) — 218 hp
Diesel, PC — July 2016 to August 2018
Engine code : CSWB
A5 (F53, F5P) — 218 hp
Diesel, PC — November 2016 to August 2018
Engine code : CSWB
A5 (F53, F5P) — 272 hp
Diesel, PC — February 2017 to December 2017
Engine code : CRTC
A5 Convertible (F57, F5E) — 218 hp
Diesel, PC — December 2016 to August 2018
Engine code : CSWB
A5 Convertible (F57, F5E) — 218 hp
Diesel, PC — March 2017 to August 2018
Engine code : CSWB
A5 Sportback (F5A, F5F) — 218 hp
Diesel, PC — September 2016 to an unspecified date
Engine code : CSWB
A5 Sportback (F5A, F5F) — 218 hp
Diesel, PC — March 2017 to August 2018
Engine code : CSWB
A5 Sportback (F5A, F5F) — 272 hp
Diesel, PC — February 2017 to December 2017
Engine code : CRTC
A6 Allroad C7 (4GH, 4GJ) — 190 hp
Diesel, PC — November 2015 to September 2018
Engine code : CZVF
A6 Allroad C7 (4GH, 4GJ) — 211 hp
Diesel, PC — September 2014 to September 2018
Engine codes: CRTF, CZVC
A6 Allroad C7 (4GH, 4GJ) — 218 hp
Diesel, PC — September 2014 to September 2018
Engine codes: CRTE, CZVA
A6 Allroad C7 (4GH, 4GJ) — 272 hp
Diesel, PC — September 2014 to September 2018
Engine code : CRTD
A6 C7 (4G2, 4GC) — 211 hp
Diesel, PC — September 2014 to September 2018
Engine codes: CRTF, CZVC
A6 C7 (4G2, 4GC) — 211 hp
Diesel, PC — September 2014 to September 2018
Engine codes: CTCB, CZVD
A6 C7 (4G2, 4GC) — 218 hp
Diesel, PC — September 2014 to September 2018
Engine codes: CTCC, CZVB
A6 C7 (4G2, 4GC) — 218 hp
Diesel, PC — September 2014 to September 2018
Engine codes: CRTE, CZVA
A6 C7 (4G2, 4GC) — 272 hp
Diesel, PC — September 2014 to September 2018
Engine code : CRTD
A6 C7 Front (4G5, 4GD) — 211 hp
Diesel, PC — September 2014 to September 2018
Engine codes: CTCB, CZVD
A6 C7 Front (4G5, 4GD) — 211 hp
Diesel, PC — September 2014 to September 2018
Engine codes: CRTF, CZVC
A6 C7 Front (4G5, 4GD) — 218 hp
Diesel, PC — September 2014 to September 2018
Engine codes: CTCC, CZVB
A6 C7 Front (4G5, 4GD) — 218 hp
Diesel, PC — September 2014 to September 2018
Engine codes: CRTE, CZVA
A6 C7 Front (4G5, 4GD) — 272 hp
Diesel, PC — September 2014 to September 2018
Engine code : CRTD
A7 Sportback (4GA, 4GF) — 190 hp
Diesel, PC — November 2015 to May 2018
Engine code : CZVE
A7 Sportback (4GA, 4GF) — 190 hp
Diesel, PC — November 2015 to May 2018
Engine codes: CZVE, CZVF
A7 Sportback (4GA, 4GF) — 211 hp
Diesel, PC — July 2014 to May 2018
Engine codes: CRTF, CTCB, CZVD, CZVC
A7 Sportback (4GA, 4GF) — 211 hp
Diesel, PC — November 2015 to May 2018
Engine codes: CTCB, CZVD, CZVC
A7 Sportback (4GA, 4GF) — 218 hp
Diesel, PC — July 2014 to May 2018
Engine codes: CRTE, CZVA
A7 Sportback (4GA, 4GF) — 218 hp
Diesel, PC — July 2014 to May 2018
Engine codes: CTCC, CZVB
A7 Sportback (4GA, 4GF) — 272 hp
Diesel, PC — May 2014 to May 2018
Engine code : CRTD
Q7 (4MB, 4MG, 4MQ) — 218 hp
Diesel, PC — June 2015 to December 2019
Engine codes: CRTE, CZZA, CZZB
Q7 (4MB, 4MG, 4MQ) — 249 hp
Diesel, PC — June 2015 to December 2019
Engine code : CVMD
Q7 (4MB, 4MG, 4MQ) — 249 hp
Diesel, PC — July 2019 to an unspecified date
Engine code : CVMD
Q7 (4MB, 4MG, 4MQ) — 272 hp
Diesel, PC — Jan 2015 to Dec 2019
Engine code : CRTC
Q7 (4MB, 4MG, 4MQ) — 374 hp
Diesel/Electrical, IT — August 2015 to December 2019
Engine code : CVZA
Q7 Van (4MB, 4MG) — 272 hp
Diesel, LCV — Jan 2015 to Dec 2019
Engine code : CRTC
Volkswagen
Amarok (2HA, 2HB, S1B, S6B, S7A, S7B, AG) — 163 hp
Diesel, PC — June 2016 to June 2020
Engine code : DDXA
Amarok (2HA, 2HB, S1B, S6B, S7A, S7B, AG) — 204 hp
Diesel, PC — June 2016 to August 2020
Engine code : DDXB
Amarok (2HA, 2HB, S1B, S6B, S7A, S7B, AG) — 224 hp
Diesel, PC — June 2016 to May 2022
Engine codes: DDXC, DDXD
Amarok Platform/Chassis (S1B, S6B, S7B) — 204 hp
Diesel, LCV — June 2016 to August 2020
Engine code : DDXB

Technical specifications

Product type: Cartridge Turbo
Engine: 3.0 TDI
Fuel: diesel; diesel/electric depending on the role
Documented power ratings: 163, 190, 204, 211, 218, 224, 249, 272 and 374 hp
Engine codes: CRTC, CSWB, CRTF, CZVC, CRTE, CZVA, CRTD, CZVF, CTCB, CZVD, CTCC, CZVB, CZVE, CZZA, CZZB, CVMD, CVZA, DDXA, DDXB, DDXC, DDXD
Documented periods: from May 2014, depending on the role

Assembly instructions

⚠️ WARNING — IMPORTANT BEFORE ASSEMBLY

Before fitting the cartridge Cartridge, it is essential to investigate and rectify the cause of the previous fault. Check the lubrication circuit, the supply and the return d’oil, as well as the cleanliness of the pipes.

Check the condition and cleanliness of the casings, the intake and the exhaust. Ensure there are no foreign objects present, prime the cartridge in accordance with the relevant guidelines and follow the manufacturer’s instructions when assembling the primer.

If a lubrication fault is not rectified, it may lead to the turbocharger failing again.

How do you choose the right turbo ?

Check the part number engraved or marked on the turbocharger dthe original, then compare it with the OEM and manufacturer’s part numbers listed on this sheet. Also check the make, model, generation, body style and power output in hp, the assembly period and the engine code. Having the same motor does not always guarantee compatibility.

⚠️ Check your turbo’s part numbers

Before placing your order, Compare the part number on your turbocharger d'origin' using the references given in this fact sheet. Having the same motor does not always guarantee compatibility.

If you are unsure, please contact us, quoting your turbo’s part number dYour vehicle’s origin and details.

Product Details
ACG-839
New
Attachments
Download

Turbo: specialists in turbochargers since 2012

ALFI TURBO specialises in the sale of turbochargers for for cars, commercial vehicles, heavy goods vehicles, construction machinery, agricultural machinery and boats: new turbochargers, remanufactured units, hybrid turbochargers, Cartridge and turbocharger spare parts. Over 20,000 items are available.

Find the right turbocharger for your engine

The turbocharger plays a vital role in the operation and performance d of a turbocharged engine. When a turbocharger needs replacing, it is important d to identify the exact part number before ordering.

ALFI TURBO supplies turbochargers for for a wide range of makes and engine types: cars, commercial vehicles, heavy goods vehicles, construction machinery, tractors and agricultural machinery, as well as various marine applications.

You can search for your turbo based on the vehicle or application, engine type, engine code, or directly using d an OEM or manufacturer part number found on your old turbocharger.

Turbo new, remanufactured, hybrid and Cartridge

Turbo new

Browse our range of new turbochargers for for diesel and petrol engines. ALFI TURBO has over 5,500 new turbochargers in stock for covering a wide range of makes, engine types and turbocharger part numbers.

View new turbochargers →

Turbo as remanufactured units

A standard exchange turbo allows you to replace a turbocharger whilst returning the old part where a deposit is required. Our catalogue includes numerous part numbers for from various makes and engine types.

View standard exchange turbochargers →

Hybrid Turbo

Hybrid turbos are designed for set-ups requiring greater air flow d and higher performance potential than a standard set-up. Specifications depend on the turbo, its tuning and the engine configuration.

View hybrid turbos →

Cartridge turbo

The turbo Cartridge, also known as the central turbo cartridge, comprises the main rotating components of the turbocharger. ALFI TURBO has over 6,000 Cartridge for turbo part numbers.

View turbo Cartridge →

for turbochargers for a wide range of applications

Our catalogue covers a wide range of d applications fitted with d a turbocharged engine.

  • diesel and petrolcars;
  • commercial vehicles;
  • heavy goods vehicles and lorries;
  • construction and civil engineeringmachinery;
  • tractors and agricultural machinery;
  • boats and marine applications.

How do you identify the correct turbo part number?

A single engine type may have been fitted with several different turbochargers depending on theYear, power output, engine version or technical evolution.. The application alone is therefore not always sufficient for to accurately identify the correct turbo.

Before ordering, note down the part numbers shown on the identification plate d of your old turbocharger. This may be d an OEM part number or d a part number from the turbo manufacturer.

Compare these part numbers with those listed on our product pages.. If in doubt, our team can help you verify the part number you are looking for before you place your order.

Turbo failure: identify the cause before replacement

A loss of power, an unusual whistling noise, oil consumption d, abnormal smoke or poor engine performance may be linked to a turbocharger fault.

However, a fault that appears to be turbo-related may also stem d from a lubrication issue, d from contaminated oil, d from a foreign object, from the intake or exhaust systems, or d from another engine peripheral component.

It is therefore important to investigate the cause of the fault before fitting a new turbo or a new Cartridge.

→ Identifying the symptoms d of a turbo failure

→ Understand the main causes of turbo failure d
