Turbo VW Polo 1.4 TSI 125 hp, 04E145704D, 04E145704Q, 04E145721G, 04E145713C, 04E145713F, 04E145721C, 9V206

  • Online only
  • New product
  • Included Gasket Kit
New
Turbo VW Polo 1.4 TSI 125 hp, 04E145704D, 04E145704Q, 04E145721G, 04E145713C, 04E145713F, 04E145721C, 9V206
  • Turbo VW Polo 1.4 TSI 125 hp, 04E145704D, 04E145704Q, 04E145721G, 04E145713C, 04E145713F, 04E145721C, 9V206
AI03-AD08
Year: Depending on the vehicle, from April 2012 to June 2024; some end dates not specified
Power: 122 and 125 hp
displacement: 1.4L
Engine code: CMBA, CXSA, CXSB, CZCA, CZDB, CZDD
Warranty: 2 years

Included Gasket Kit

€303.60 VAT included

253 tax excl.

Quantity
Last items in stock

Description

This turbocharger is designed for the following petrol engines: 1., 4 TSI and 1., 4 TFSI with 122 or 125 hp, as listed below:.. It covers various applications Audi, SEAT, Škoda and Volkswagen, including the VW Polo 1., 4 TSI, 125 hp fitted with the CZCA engine.

Compatibility depends on the original turbo part number d, the engine code, the generation, the body style and the production period of the vehicle.

Turbo part numbers

OEM part numbers

04E145704D
04E145704Q
04E145721G
04E145713C
04E145713F
04E145721C
04E145715H
04E145704DX
04E145704QX
04E145721GX
04E145713CX
04E145713FX
04E145721CX
04E145715HX
04E145704DV
04E145704QV
04E145721GV
04E145713CV
04E145713FV
04E145721CV
04E145715HV

Manufacturer’s part numbers

9V206
F31CEG-SR045
F31CEGSR045

Compatible vehicles and applications

AUDI
A1 (8X1, 8XK) — 1.4 TFSI 125 hp
3- or 5-door saloon, petrol — 11/2014 to 10/2018
Engine codes: CZCA, CZDD
A1 Sportback (8XA, 8XF) — 1.4 TFSI 125 hp
3- or 5-door hatchback, petrol — Nov 2014 to Oct 2018
Engine codes: CZCA, CZDD
A3 (8V1, 8VK) — 1.4 TFSI 122 hp
3- or 5-door saloon, petrol — 04/2012 to 05/2014
Engine codes: CMBA, CXSA
A3 (8V1, 8VK) — 1.4 TFSI 125 hp
3- or 5-door hatchback, petrol — 05/2014 to 08/2016
Engine codes: CXSB, CZCA
A3 Convertible (8V7, 8VE) — 1.4 TFSI 125 hp
Convertible, petrol — 02/2014 to 07/2016
Engine codes: CXSB, CZCA
A3 Saloon (8VS, 8VM) — 1.4 TFSI 125 hp
Three-box saloon, petrol — 09/2013 to 08/2016
Engine codes: CXSB, CZCA
A3 Sportback (8VA, 8VF) — 1.4 TFSI 122 hp
3- or 5-door hatchback, petrol — 09/2012 to 10/2020
Engine codes: CMBA, CXSA
A3 Sportback (8VA, 8VF) — 1.4 TFSI 125 hp
3- or 5-door hatchback, petrol — May 2014 to August 2016
Engine codes: CXSB, CZCA
SEAT
Leon (5F1) — 1.4 TSI 122 hp
3- or 5-door hatchback, petrol — 11/2012 to 10/2016
Engine codes: CMBA, CXSA
Leon (5F1) — 1.4 TSI 125 hp
3- or 5-door hatchback, petrol — May 2014 to August 2020
Engine code : CZCA
Leon Estate/Hatchback (5F1) — 1.4 TSI 122 hp
Estate or hatchback, petrol — 09/2012 to 10/2016
Engine codes: CMBA, CXSA
Leon SC (5F5) — 1.4 TSI 122 hp
Coupé, petrol — 02/2013 to 06/2015
Engine codes: CMBA, CXSA
Leon SC (5F5) — 1.4 TSI 125 hp
Coupé, petrol — May 2014 to August 2018
Engine code : CZCA
Leon ST (5F8) — 1.4 TSI 122 hp
Estate, petrol — 09/2012 to 06/2015
Engine codes: CMBA, CXSA
Leon ST (5F8) — 1.4 TSI 125 hp
Estate, petrol — May 2014 to August 2018
Engine code : CZCA
Toledo IV (KG3) — 1.4 TSI 125 hp
3- or 5-door hatchback, petrol — May 2015 to April 2019
Engine code : CZCA
Skoda
Fabia III (NJ3) — 1.4 TSI R5 125 hp
3- or 5-door hatchback, petrol — 02/2018 to 06/2021
Engine code : CZCA
Kodiaq I (NS6, NS7, NV7) — 1.4 TSI 125 hp
SUV, petrol — from 10/2016, end date unspecified
Engine codes: CZCA, CZDB
Rapid (NH3, NK3, NK6) — 1.4 TSI 125 hp
3- or 5-door saloon, petrol — 05/2015 to 03/2022
Engine code : CZCA
Rapid Spaceback (NH1) — 1.4 TSI 125 hp
3- or 5-door hatchback, petrol — May 2015 to December 2019
Engine code : CZCA
Superb III (3V3) — 1.4 TSI 125 hp
3- or 5-door saloon, petrol — 03/2015 to 06/2024
Engine code : CZCA
Superb III Estate (3V5) — 1.4 TSI 125 hp
Estate, petrol — 03/2015 to 06/2024
Engine code : CZCA
Yeti (5L) — 1.4 TSI 125 hp
SUV, petrol — 05/2015 to 12/2017
Engine code : CZCA
Volkswagen
Golf VI Convertible (517) — 1.4 TSI 125 hp
Convertible, petrol — 11/2013 to 05/2016
Engine codes: CXSB, CZCA
Golf VII (5G1, BQ1, BE1, BE2) — 1.4 TSI 122 hp
3- or 5-door saloon, petrol — Nov 2012 to Mar 2017
Engine codes: CMBA, CXSA
Golf VII (5G1, BQ1, BE1, BE2) — 1.4 TSI 125 hp
3- or 5-door hatchback, petrol — May 2014 to August 2020
Engine code : CZCA
Golf VII Variant (BA5, BV5) — 1.4 TSI 125 hp
Estate, petrol — May 2014 to August 2020
Engine codes: CZCA, CZDD
Golf Sportsvan VII (AM1, AN1) — 1.4 TSI 125 hp
3- or 5-door saloon, petrol — 04/2014 to 08/2020
Engine code : CZCA
Jetta IV (162, 163, AV3, AV2) — 1.4 TSI 125 hp
Three-box saloon, petrol — 08/2014 to 12/2017
Engine code : CZCA
Passat B8 (3G2, CB2) — 1.4 TSI 125 hp
Three-box saloon, petrol — Nov 2014 to Nov 2018
Engine code : CZCA
Passat B8 Variant (3G5, CB5) — 1.4 TSI 125 hp
Estate, petrol — Nov 2014 to Nov 2018
Engine code : CZCA
Polo Liftback (CK4, CK5) — 1.4 TSI 125 hp
3- or 5-door saloon, petrol — 05/2020 to 03/2022
Engine code : CZCA
Polo V three-box saloon (602, 604, 612, 614) — 1.4 TSI 125 hp
Three-box saloon, petrol — May 2016 to March 2020
Engine code : CZCA
Scirocco III (137, 138) — 1.4 TSI 125 hp
Coupé, petrol — Nov 2013 to Nov 2017
Engine codes: CXSB, CZCA
Tiguan (AD1, AX1) — 1,.,4 TSI,125 hp
SUV, petrol — Jan 2016 to Mar 2022
Engine codes: CZCA, CZDB

Technical specifications

Product type: Turbo
Engine variants: 1.4 TSI and 1.4 TFSI
displacement: 1.4 L
Fuel: Essence
Power outputs: 122 and 125 hp
Engine codes: CMBA, CXSA, CXSB, CZCA, CZDB, CZDD
Documented production periods: depending on the vehicle, from 04/2012 to 06/2024; some end dates unspecified

Fitting advice

⚠️ WARNING — IMPORTANT BEFORE INSTALLATION

Before fitting, it is essential to identify and rectify the cause of the previous failure. Check the lubrication circuit, the oil supply and return das well as the cleanliness of the pipes.

Check the inlet for any foreign objects. Prime the system in accordance with the applicable recommendations and follow the vehicle manufacturer’s instructions.

A lubrication fault that is not rectified may lead to further damage to the turbocharger.

How do you identify the correct turbo?

Check the part number marked on the original turbo d, then compare the OEM and manufacturer part numbers.. Also check the make, model, generation, body style, engine type, power output at hp, years of manufacture and engine code.

An identical engine specification does not always guarantee compatibility: there may be several different set-ups depending on the vehicle version.

⚠️ Check your turbo’s part numbers

Before ordering, compare the part number marked on your original turbo d with the part numbers listed in this product sheet. An identical engine specification does not always guarantee compatibility.

If in doubt, please contact us with the part number clearly visible on your turbo and your vehicle details.

Product Details
AI03-AD08
3701803908766
New
Attachments
Download

Turbo: specialists in turbochargers since 2012

ALFI TURBO specialises in the sale of turbochargers for for cars, commercial vehicles, heavy goods vehicles, construction machinery, agricultural machinery and boats: new turbochargers, remanufactured units, hybrid turbochargers, Cartridge and turbocharger spare parts. Over 20,000 items are available.

Find the right turbocharger for your engine

The turbocharger plays a vital role in the operation and performance d of a turbocharged engine. When a turbocharger needs replacing, it is important d to identify the exact part number before ordering.

ALFI TURBO supplies turbochargers for for a wide range of makes and engine types: cars, commercial vehicles, heavy goods vehicles, construction machinery, tractors and agricultural machinery, as well as various marine applications.

You can search for your turbo based on the vehicle or application, engine type, engine code, or directly using d an OEM or manufacturer part number found on your old turbocharger.

Turbo new, remanufactured, hybrid and Cartridge

Turbo new

Browse our range of new turbochargers for for diesel and petrol engines. ALFI TURBO has over 5,500 new turbochargers in stock for covering a wide range of makes, engine types and turbocharger part numbers.

View new turbochargers →

Turbo as remanufactured units

A standard exchange turbo allows you to replace a turbocharger whilst returning the old part where a deposit is required. Our catalogue includes numerous part numbers for from various makes and engine types.

View standard exchange turbochargers →

Hybrid Turbo

Hybrid turbos are designed for set-ups requiring greater air flow d and higher performance potential than a standard set-up. Specifications depend on the turbo, its tuning and the engine configuration.

View hybrid turbos →

Cartridge turbo

The turbo Cartridge, also known as the central turbo cartridge, comprises the main rotating components of the turbocharger. ALFI TURBO has over 6,000 Cartridge for turbo part numbers.

View turbo Cartridge →

for turbochargers for a wide range of applications

Our catalogue covers a wide range of d applications fitted with d a turbocharged engine.

  • diesel and petrolcars;
  • commercial vehicles;
  • heavy goods vehicles and lorries;
  • construction and civil engineeringmachinery;
  • tractors and agricultural machinery;
  • boats and marine applications.

How do you identify the correct turbo part number?

A single engine type may have been fitted with several different turbochargers depending on theYear, power output, engine version or technical evolution.. The application alone is therefore not always sufficient for to accurately identify the correct turbo.

Before ordering, note down the part numbers shown on the identification plate d of your old turbocharger. This may be d an OEM part number or d a part number from the turbo manufacturer.

Compare these part numbers with those listed on our product pages.. If in doubt, our team can help you verify the part number you are looking for before you place your order.

Turbo failure: identify the cause before replacement

A loss of power, an unusual whistling noise, oil consumption d, abnormal smoke or poor engine performance may be linked to a turbocharger fault.

However, a fault that appears to be turbo-related may also stem d from a lubrication issue, d from contaminated oil, d from a foreign object, from the intake or exhaust systems, or d from another engine peripheral component.

It is therefore important to investigate the cause of the fault before fitting a new turbo or a new Cartridge.

→ Identifying the symptoms d of a turbo failure

→ Understand the main causes of turbo failure d

ALFI TURBO, specialists in turbochargers since 2012

Since 2012, ALFI TURBO has been assisting private individuals and professionals in identifying and replacing turbochargers.

  • over 20,000 items in the catalogue;
  • over 5,500 new turbochargers in stock;
  • over 6,000 ‘ Cartridge ’ available;
  • new turbochargers, remanufactured units, hybrid units and Cartridge;
  • diesel and petrol engines;
  • a wide range of applications for road, agricultural, industrial and marine use;
  • fast delivery in France and across Europe;
  • warranty of up to 2 years depending on the product and applicable conditions.

BEFORE REPLACING A TURBO

A turbocharger failure may be the result d of another engine problem. Before fitting d a new turbo or Cartridge, identify and rectify the cause of the original fault to d avoid d damaging the new part.

Need d'help for finding your turbo?

Do you have a turbocharger part number but can’t find the matching part? Are you unsure which part number to choose? Send us the details from your old turbo so that our team can help you identify the part you’re looking for.

CONTACT ALFI TURBO
