Turbo Audi A1 1 4 125 , 04E145704D, 04E145704Q, 04E145721G, 04E145713C, 04E145713F, 04E145721C, 9V206. TFSI hp

  • Online only
  • New product
  • Included Gasket Kit
New
Turbo Audi A1 1 4 125 , 04E145704D, 04E145704Q, 04E145721G, 04E145713C, 04E145713F, 04E145721C, 9V206. TFSI hp
  • Turbo Audi A1 1 4 125 , 04E145704D, 04E145704Q, 04E145721G, 04E145713C, 04E145713F, 04E145721C, 9V206. TFSI hp
AI03-AD08
Years: 2012–2022
Power output: 122 and 125 hp
displacement: 1.4 L
Engine codes: CMBA, CXSA, CXSB, CZCA, CZDB, CZDD
Warranty: 2 years

Included Gasket Kit

€303.60 VAT included

253 tax excl.

Quantity
Last items in stock

Description

Turbo for Audi 1.4 TFSI and SEAT, Škoda and Volkswagen 1.4 TSI.

Petrol engines producing 122 or 125 hp depending on the version. 2-year warranty.

Turbo part numbers

OEM part numbers

04E145704D, 04E145704Q, 04E145721G, 04E145713C, 04E145713F, 04E145721C, 04E145715H, 04E145704DX, 04E145704QX, 04E145721GX, 04E145713CX, 04E145713FX, 04E145721CX, 04E145715HX, 04E145704DV, 04E145704QV, 04E145721GV, 04E145713CV, 04E145713FV, 04E145721CV, 04E145715HV

Manufacturer’s part numbers

9V206, F31CEG-SR045, F31CEGSR045

Vehicles and applications

Model Engine Specified period Engine codes Power
AUDI
A1 (8X1, 8XK) 1.4 TFSI Nov 2014 to Oct 2018 CZCA, CZDD 125 hp
A1 Sportback (8XA, 8XF) 1.4 TFSI Nov 2014 to Oct 2018 CZCA, CZDD 125 hp
A3 (8V1, 8VK) 1.4TFSI April 2012 to May 2014 CMBA, CXSA 122 hp
A3 (8V1, 8VK) 1.4TFSI May 2014 to August 2016 CXSB, CZCA 125 hp
A3 Saloon (8VS, 8VM) 1.4 TFSI September 2013 to August 2016 CXSB, CZCA 125 hp
A3 Convertible (8V7, 8VE) 1.4 TFSI Feb 2014 to Jul 2016 CXSB, CZCA 125 hp
A3 Sportback (8VA, 8VF) 1.4 TFSI September 2012 to October 2020 CMBA, CXSA 122 hp
A3 Sportback (8VA, 8VF) 1.4TFSI May 2014 to August 2016 CXSB, CZCA 125 hp
SEAT
Leon (5F1) 1.4 TSI Nov 2012 to Oct 2016 CMBA, CXSA 122 hp
Leon (5F1) 1.4TSI May 2014 to August 2020 CZCA 125 hp
Leon Estate (5F1) 1.4TSI 09/2012 to 10/2016 CMBA, CXSA 122 hp
Leon SC (5F5) 1.4TSI Feb 2013 to Jun 2015 CMBA, CXSA 122 hp
Leon SC (5F5) 1.4TSI May 2014 to August 2018 CZCA 125 hp
Leon ST (5F8) 1.4TSI 09/2012 to 06/2015 CMBA, CXSA 122 hp
Leon ST (5F8) 1.4TSI May 2014 to August 2018 CZCA 125 hp
Toledo IV (KG3) 1.4TSI May 2015 to April 2019 CZCA 125 hp
ŠKODA
Fabia III (NJ3) 1.4TSI R5 Feb 2018 to Jun 2021 CZCA 125 hp
Kodiaq I (NS6, NS7, NV7) 1.4TSI From 10/2016 CZCA, CZDB 125 hp
Rapid (NH3, NK3, NK6) 1.4TSI May 2015 to March 2022 CZCA 125 hp
Rapid Spaceback (NH1) 1.4TSI May 2015 to December 2019 CZCA 125 hp
Superb III 1.4TSI Mar 2015 to Jun 2024 CZCA 125 hp
Superb III Estate (3V5) 1.4TSI March 2015 to June 2024 CZCA 125 hp
Yeti (5L) 1.4TSI May 2015 to December 2017 CZCA 125 hp
Volkswagen
Golf VI Cabriolet (517) 1.4TSI Nov 2013 to May 2016 CXSB, CZCA 125 hp
Golf VII (5G1, BQ1, BE1, BE2) 1.4TSI Nov 2012 to Mar 2017 CMBA, CXSA 122 hp
Golf VII (5G1, BQ1, BE1, BE2) 1.4TSI May 2014 to August 2020 CZCA 125 hp
Golf VII Variant (BA5, BV5) 1.4TSI May 2014 to August 2020 CZCA, CZDD 125 hp
Golf Sportsvan VII (AM1, AN1) 1.4TSI April 2014 to August 2020 CZCA 125 hp
Jetta IV (162, 163, AV3, AV2) 1.4TSI August 2014 to December 2017 CZCA 125 hp
Passat B8 Saloon (3G2, CB2) 1.4TSI Nov 2014 to Nov 2018 CZCA 125 hp
Passat B8 Variant (3G5, CB5) 1.4TSI Nov 2014 to Nov 2018 CZCA 125 hp
Polo V Saloon (602, 604, 612, 614) 1.4TSI May 2016 to March 2020 CZCA 125 hp
Polo Liftback (CK4, CK5) 1.4TSI May 2020 to March 2022 CZCA 125 hp
Scirocco III (137, 138) 1.4TSI Nov 2013 to Nov 2017 CXSB, CZCA 125 hp
Tiguan (AD1, AX1) 1.4TSI Jan 2016 to Mar 2022 CZCA, CZDB 125 hp

Technical specifications

Product type: Turbocharger
Engine variants: 1.4 TFSI and 1.4 TSI petrol
Power outputs: 122 and 125 hp
Engine codes: CMBA, CXSA, CXSB, CZCA, CZDB, CZDD
Warranty: 2 years

Check the part number before ordering

Compare the full part number of your original turbocharger with the OEM and manufacturer part numbers listed on this page. Also check the engine code, power output and production period for your version.

Product Details
AI03-AD08
3701803908766
New
Attachments
Download

Turbo: specialists in turbochargers since 2012

ALFI TURBO specialises in the sale of turbochargers for for cars, commercial vehicles, heavy goods vehicles, construction machinery, agricultural machinery and boats: new turbochargers, remanufactured units, hybrid turbochargers, Cartridge and turbocharger spare parts. Over 20,000 items are available.

Find the right turbocharger for your engine

The turbocharger plays a vital role in the operation and performance d of a turbocharged engine. When a turbocharger needs replacing, it is important d to identify the exact part number before ordering.

ALFI TURBO supplies turbochargers for for a wide range of makes and engine types: cars, commercial vehicles, heavy goods vehicles, construction machinery, tractors and agricultural machinery, as well as various marine applications.

You can search for your turbo based on the vehicle or application, engine type, engine code, or directly using d an OEM or manufacturer part number found on your old turbocharger.

Turbo new, remanufactured, hybrid and Cartridge

Turbo new

Browse our range of new turbochargers for for diesel and petrol engines. ALFI TURBO has over 5,500 new turbochargers in stock for covering a wide range of makes, engine types and turbocharger part numbers.

View new turbochargers →

Turbo as remanufactured units

A standard exchange turbo allows you to replace a turbocharger whilst returning the old part where a deposit is required. Our catalogue includes numerous part numbers for from various makes and engine types.

View standard exchange turbochargers →

Hybrid Turbo

Hybrid turbos are designed for set-ups requiring greater air flow d and higher performance potential than a standard set-up. Specifications depend on the turbo, its tuning and the engine configuration.

View hybrid turbos →

Cartridge turbo

The turbo Cartridge, also known as the central turbo cartridge, comprises the main rotating components of the turbocharger. ALFI TURBO has over 6,000 Cartridge for turbo part numbers.

View turbo Cartridge →

for turbochargers for a wide range of applications

Our catalogue covers a wide range of d applications fitted with d a turbocharged engine.

  • diesel and petrolcars;
  • commercial vehicles;
  • heavy goods vehicles and lorries;
  • construction and civil engineeringmachinery;
  • tractors and agricultural machinery;
  • boats and marine applications.

How do you identify the correct turbo part number?

A single engine type may have been fitted with several different turbochargers depending on theYear, power output, engine version or technical evolution.. The application alone is therefore not always sufficient for to accurately identify the correct turbo.

Before ordering, note down the part numbers shown on the identification plate d of your old turbocharger. This may be d an OEM part number or d a part number from the turbo manufacturer.

Compare these part numbers with those listed on our product pages.. If in doubt, our team can help you verify the part number you are looking for before you place your order.

Turbo failure: identify the cause before replacement

A loss of power, an unusual whistling noise, oil consumption d, abnormal smoke or poor engine performance may be linked to a turbocharger fault.

However, a fault that appears to be turbo-related may also stem d from a lubrication issue, d from contaminated oil, d from a foreign object, from the intake or exhaust systems, or d from another engine peripheral component.

It is therefore important to investigate the cause of the fault before fitting a new turbo or a new Cartridge.

→ Identifying the symptoms d of a turbo failure

→ Understand the main causes of turbo failure d

ALFI TURBO, specialists in turbochargers since 2012

Since 2012, ALFI TURBO has been assisting private individuals and professionals in identifying and replacing turbochargers.

  • over 20,000 items in the catalogue;
  • over 5,500 new turbochargers in stock;
  • over 6,000 ‘ Cartridge ’ available;
  • new turbochargers, remanufactured units, hybrid units and Cartridge;
  • diesel and petrol engines;
  • a wide range of applications for road, agricultural, industrial and marine use;
  • fast delivery in France and across Europe;
  • warranty of up to 2 years depending on the product and applicable conditions.

BEFORE REPLACING A TURBO

A turbocharger failure may be the result d of another engine problem. Before fitting d a new turbo or Cartridge, identify and rectify the cause of the original fault to d avoid d damaging the new part.

Need d'help for finding your turbo?

Do you have a turbocharger part number but can’t find the matching part? Are you unsure which part number to choose? Send us the details from your old turbo so that our team can help you identify the part you’re looking for.
