Hybrid Turbo 2.8 CDTi/TiD 230/250/255/280 hp – 55557012, 49389-01700

  • Online only
Hybrid
Hybrid Turbo 2.8 CDTi 230 250 255 280 49389-01710   49389-01700  5860017  55557012  55564299
  • Hybrid Turbo 2.8 CDTi 230 250 255 280 49389-01710   49389-01700  5860017  55557012  55564299
  • Hybrid Turbo 2.8 CDTi 230 250 255 280 49389-01710   49389-01700  5860017  55557012  55564299
  • Hybrid Turbo 2.8 CDTi 230 250 255 280 49389-01710   49389-01700  5860017  55557012  55564299
49389-01700
Year: From 2005 onwards, depending on allocation
Power: 230, 250, 255 and 280 hp
displacement: 2.8 litres
Engine code: Not specified
Gasket kit
Preparation course
Exchange
€503.99 VAT included

419.99125 tax excl.

Quantity
Manufacturing time: 15-20 working days

Description

This hybrid turbo is designed for the 2.8 engines in the following models: Cadillac BLS, Opel Signum and Opel Vectra C Phase 2, as detailed below:. Its design allows for installation plug & play without any modifications to the vehicle’s existing system, whilst offering several levels of internal tuning.

Depending on the upgrade package chosen, the conversion combines a high-flow MFS compressor wheel, a 360° thrust bearing, recontoured casings or an impeller oversized. The specifications for each upgrade package must be selected according to the engine configuration and intended use.

Available preparations — Stage 1, Stage 2 and Stage 3

Stage 1

Compressor wheel: MFS high-flow
Thrust bearing system: 360° thrust bearing
Balancing: High-speed balancing at 150,000 rpm on a Cimat VSR test bench

This modification primarily affects the compressor section in order d to adapt the air flow rate d whilst maintaining a direct-mount configuration.

Stage 2

Compressor impeller: MFS high-flow oversized
d' intake housing: Reprofiled for accommodate the new impeller oversized
Thrust bearing system: 360° thrust bearing
Balancing: High-speed balancing at 150,000 rpm on a Cimat VSR test bench

The Stage 2 combines a oversized compressor wheel with a reprofiled d intake housing. This modification is designed to alter the turbo’s compression capacity and air flow rate d.

Stage 3

Compressor wheel: MFS high-flow oversized
d intake housing: Reprofiled for to accommodate the new impeller oversized
Thrust bearing system: 360° thrust bearing
Turbine impeller: High-flow oversized
Turbine casing: Reprofiled for ly to accommodate the new impeller oversized
Balancing: High-speed balancing at 150,000 rpm on a Cimat VSR test bench

This version features modifications to the compressor and turbine sides. The resulting performance depends on the overall configuration, in particular the engine management system, boost pressure and peripheral circuits.

What is a hybrid turbo?

A hybrid turbo utilises a turbocharger architecture adapted for accommodate modified internal components. Depending on the stage, the modification may involve the compressor wheel, the turbine wheel, the housings, the thrust bearing system or the balancing.

The aim is d to adapt the compression capacity and air flow rate d. However, a hybrid turbo is not defined solely by the appearance of its impeller: the dimensions, geometry, machining of the housings and the balance between the compressor and turbine sides also play a role.

MFS compressor wheel: standard or ‘ Performance ’?

MFS stands for ‘Milled From Solid’, meaning a wheel machined from a solid block. This technology describes its manufacturing process; on its own, it is not sufficient to demonstrate an increase in airflow d'air.

A standard MFS impeller may retain a geometry equivalent to the original. An ‘ Performance ’ MFS impeller may feature a geometry adapted to the modification, for example a different profile or dimensions where such modifications are intended. For this product, the wheels shown are made from forged aluminium, whilst Stages 2 and 3 use a version oversized.

A standard MFS impeller can be just as shiny as an MFS impeller Performance. It is not its appearance that determines its performance, but its geometry and its ability to move more d air. A higher airflow can contribute to power output with a suitably tuned engine.

Why does the geometry of the blades influence the air flow rate d?

The compressor impeller draws in and then compresses the air sent to the engine. Its diameter, profile, height, width and blade arrangement influence its aerodynamic behaviour and the amount d of air displaced within certain operating ranges.

The result also depends on the housings, the turbine wheel, the boost pressure and the engine set-up. A larger wheel therefore does not automatically produce a better result in all conditions and may alter the turbocharger’s response time.

Reliability and balancing of the hybrid turbo

The 360° thrust bearing fitted to all three stages helps to distribute axial forces around the shaft. It must operate with adequate lubrication and does not protect the turbo from the consequences d of a fault d in the oil supply or d of incorrect fitting.

Every engine preparation includes d'high-speed balancing at 150,000 rpm on a Cimat VSR test bench. This process helps to minimise vibrations and mechanical stresses on the rotor during operation.

Engine remapping and tuning

Operating d a hybrid turbo requires engine management that is consistent with the chosen tuning package. The mapping, boost pressure, fuel injection, exhaust and cooling must be monitored or adjusted according to the configuration. The wastegate must be adjusted during ECU remapping. The transmission and other stressed components must also be checked in accordance with the vehicle.

Turbo part numbers

Manufacturer’s part numbers

49389-01700
49389-01710

OEM part numbers

5860017
55557012
55564299

Compatible vehicles and applications

Cadillac

BLS 2.8 V6 — 255 hp
Engine 2.8 V6 — from 2005, end dateunspecified
Engine code : unspecified
BLS 2.8 T — 255 hp
Engine 2.8 T — from 2008, end date unspecified
Engine code : unspecified

Opel

Signum 2.8 i — 280 hp
Engine 2.8 i — from 2005, end date unspecified
Engine code : unspecified
Vectra C Phase 2 2.8 i — 230 hp
Engine 2.8 i — from 2005, end date unspecified
Engine code : unspecified
Vectra C Phase 2 2.8 i — 250 / 255 hp
Engine 2.8 i — from 2005, end date unspecified
Engine code : unspecified
Vectra C Phase 2 2.8 i — 280 hp
Engine 2.8 i — from 2005, end date unspecified
Engine code : unspecified

Additional technical specifications

Product type: Hybrid Turbo
Engine: 2-.8
displacement: 2.8 litres
Documented power outputs: 230, 250, 255 and 280 hp
Documented period: From 2005 onwards, depending on application
Installation: Plug & play, no modifications to the existing system required

Installation advice

⚠️ WARNING — IMPORTANT BEFORE INSTALLATION

Before fitting, identify and rectify the cause of the previous fault. Check the lubrication circuit, the oil supply and return d as well as the cleanliness of all pipes.

Check the inlet for any foreign objects. Prime the system in accordance with the applicable guidelines and follow the vehicle manufacturer’s instructions.

A lubrication fault that is not rectified may lead to the turbocharger failing again.

How do you identify the correct turbo?

Check the part number engraved or marked on the original turbo d, then compare the OEM and manufacturer part numbers.. Also check the make, model, generation, engine type, power output at hp, theYear and the engine code where available. An identical engine type is not always sufficient to confirm compatibility.

⚠️ Check your turbo’s part numbers

Before ordering, compare the part number marked on your original turbo d with the part numbers listed in this product sheet. An identical engine specification does not always guarantee compatibility.

If in doubt, contact our team with the part number of your original turbo d and your vehicle details.
