Hybrid Turbo 2.2 HDi/MJTD 101, 110, 120, 130, 131 hp – 0375K7, 49131-05210

  • Online only
Hybrid
  • Hybrid Turbo 1.4 / 2.2 / Hdi Tdci Mjtd, 49131-05200, 49131-05210, 49131-05212, 49131-05252, 0375K7, 6U3Q6K682AE
HYBM03-200-987
Year: April 2006 to December 2020, depending on assignment
Power: 101, 110, 120, 130 and 131 hp
displacement: 2.2
Engine code: 4HV, 4HU, 4HG, 4HH (P22DTE)
Exchange
Gasket kit
Preparation course
€252.00 VAT included

210 tax excl.

Quantity
Manufacturing time: 15-20 working days

Description

This hybrid turbo for engine variants 2.2 HDi and MJTD benefits from d’a preparation designed to adjust the compression capacity and flow rate dair. Depending on the course chosen, the student receives a high-flow MFS compressor wheel, a 360° bearing stop and high-speed balancing on a Cimat VSR bench..

The documented assignments relate in particular to Citroën Jumper III, Fiat Ducato and Peugeot Boxers from 101 to 131 hp. Compatibility must be confirmed using the turbo’s part number d’origin’.

Available products — Stage 1, Stage 2 and Stage 2+

Stage 1
Compressor wheel: High-capacity MFS
Stop: 360° bearing
Balancing: high speed at 150,000 rpm on a Cimat VSR test bench
This configuration affects the compressor wheel whilst retaining the documented modifications specific to the Stage 1. It aims to adjust the flow rate d’air without any guarantee of ultimate power’.
Stage 2
Compressor wheel: High-capacity MFS oversized
Carter d’Admission:’ reprofiled for to receive the new wheel oversized
Stop: 360° bearing
Balancing: high speed at 150,000 rpm on a Cimat VSR test bench
Reprofiling the casing allows d’fit the wheel’ oversized. This change may affect the compressor’s flow rate and behaviour; its operation depends on the engine configuration and the mapping.
Stage 2+
Compressor wheel: High-capacity MFS oversized
Carter d’Admission:’ reprofiled for to receive the new wheel oversized
Stop: 360° bearing
Balancing: high speed at 150,000 rpm on a Cimat VSR test bench
The specifications provided for The features of this version are identical to those listed above. No additional undocumented mechanical differences are attributed to the Stage 2+.

What is a hybrid turbo ?

A hybrid turbo utilises a turbocharger design that has been adapted to accommodate modified internal components. Depending on the design, modifications may relate to the compressor impeller, its dimensions, the geometry of the blades, the casings, the turbine impeller, the thrust bearing or the balancing.
The aim is d’adjust the compression capacity and flow rate’ dair. However, a hybrid turbo is not defined solely by the appearance of its impeller: the compatibility between the components and the engine tuning remains crucial.

MFS compressor wheel: standard or Performance ? ?

MFS stands for ‘Milled From Solid’, meaning a wheel machined from a solid block. This manufacturing process does not, on its own, guarantee an increase in throughput. A standard MFS wheel can retain a geometry equivalent to the original, whilst a performance-oriented wheel may feature a profile or dimensions tailored to the purpose of the modification.
A standard MFS wheel can be just as shiny as an MFS wheel Performance. It is not its appearance that determines its performance, but its geometry and its ability to move more dair. The product documentation states that it features a forged aluminium wheel, which is lighter, larger and taller than the original, as advertised for allow for a further 15 per cent reduction. However, the result obtained depends on the overall engine configuration.

Why does the geometry of the blades affect the flow rate? d’air ?

The compressor wheel draws in and then compresses the air fed to the engine. Its diameter, profile, height, width and the arrangement of its blades all influence its aerodynamic behaviour. The right geometry can move more dair under certain conditions, but the result also depends on the casings, the turbine, the boost pressure and the mapping. A larger wheel therefore does not automatically guarantee better performance and may affect response time.

Reliability and balancing of the hybrid turbocharger

The documented 360° stop distributes axial forces over a wide area. Balancing the rotor at 150,000 rpm on a Cimat VSR test bench helps to minimise vibrations and mechanical stresses. However, these measures do not compensate for incorrect installation or a lack of lubrication.

Engine remapping and tuning

The farm dA hybrid turbo may require adjustments to the mapping, boost pressure and wastegate setting. Depending on the level of preparation, the fuel injection, exhaust, cooling, intake and transmission systems must also be checked or adjusted. The editing dA hybrid turbo does not automatically guarantee a power boost.

Turbo part numbers

OEM part numbers
6U3Q6K682AC
6U3Q6K682AE
0375K7
1651753280
6U3Q6K682AF
9659765280
71789727
Manufacturer’s part numbers
49131-05200
49131-05210
49131-05212
49131-05252

Compatible vehicles and assignments

CITROËN
Jumper III Light Commercial Vehicle — 101 hp
Diesel — April 2006 to an unspecified date
Engine code : 4HV (P22DTE)
Jumper III LCV Bus — 110 hp
Diesel — July 2011 to December 2020
Engine code : 4HG (P22DTE)
Jumper III LCV Bus — 120 hp
Diesel — April 2006 to December 2016
Engine code : 4HU (P22DTE)
Jumper III LCV Platform/Chassis — 101 hp
Diesel — April 2006 to an unspecified date
Engine code : 4HV (P22DTE)
Jumper III LCV Platform/Chassis — 110 hp
Diesel — July 2011 to December 2020
Engine code : 4HG (P22DTE)
Jumper III LCV Platform/Chassis — 120 hp
Diesel — April 2006 to December 2016
Engine code : 4HU (P22DTE)
Jumper III Van LCV — 101 hp
Diesel — April 2006 to December 2012
Engine code : 4HV (P22DTE)
Jumper III Van LCV — 110 hp
Diesel — July 2011 to December 2020
Engine code : 4HG (P22DTE)
Jumper III Van LCV — 120 hp
Diesel — April 2006 to December 2016
Engine code : 4HU (P22DTE)
Jumper III Van LCV — 130 hp
Diesel — January 2012 to May 2016
Engine code : 4HH (P22DTE)
Fiat
Ducato Bus (250_) LCV — 101 hp
Diesel — July 2006 to May 2011
Engine code : 4HV
Ducato Platform/Chassis (250_) LCV — 101 hp
Diesel — July 2006 to May 2011
Engine code : 4HV
Ducato Van (250_) LCV — 101 hp
Diesel — July 2006 to May 2011
Engine code : 4HV
Peugeot
Boxer Bus LCV — 101 hp
Diesel — April 2006 to an unspecified date
Engine code : 4HV (P22DTE)
Boxer Bus LCV — 110 hp
Diesel — March 2011 to December 2020
Engine code : 4HG (P22DTE)
Boxer Bus LCV — 120 hp
Diesel — April 2006 to December 2016
Engine code : 4HU (P22DTE)
Boxer Platform/LCV Chassis — 101 hp
Diesel — April 2006 to an unspecified date
Engine code : 4HV (P22DTE)
Boxer Platform/LCV Chassis — 110 hp
Diesel — March 2011 to December 2020
Engine code : 4HG (P22DTE)
Boxer Platform/LCV Chassis — 120 hp
Diesel — April 2006 to December 2016
Engine code : 4HU (P22DTE)
Boxer Platform/LCV Chassis — 130 hp
Diesel — March 2011 to an unspecified date
Engine code : 4HH (P22DTE)
Boxer Van LCV — 101 hp
Diesel — April 2006 to an unspecified date
Engine code : 4HV (P22DTE)
Boxer Van LCV — 110 hp
Diesel — March 2011 to December 2020
Engine code : 4HG (P22DTE)
Boxer Van LCV — 120 hp
Diesel — April 2006 to December 2016
Engine code : 4HU (P22DTE)
Boxer Van LCV — 131 hp
Diesel — March 2011 to an unspecified date
Engine code : 4HH (P22DTE)

Additional technical specifications

Product type: hybrid turbo
Engine: 2.2 HDi / MJTD
Fuel: diesel
Documented power ratings: 101, 110, 120, 130 and 131 hp
Engine codes: 4HV, 4HU, 4HG, 4HH (P22DTE)
Documented periods: from April 2006 to December 2020, depending on the assignment, with some end dates not specified

Assembly instructions

⚠️ WARNING — IMPORTANT BEFORE ASSEMBLY
Identify and rectify the cause of the previous fault. Check the lubrication circuit, as well as the supply and return lines doil. Check that the ducts and the intake are clean and free from foreign objects. Carry out the priming in accordance with the relevant guidelines and follow the manufacturer’s instructions.
If a lubrication fault is not rectified, it may lead to the turbocharger failing again.

How do you choose the right turbo ?

Check the turbo part number d’origin, OEM and manufacturer part numbers, as well as the make, model, generation, body style, engine type, power output, production period and engine code. The same engine can be fitted with several different turbo set-ups.
⚠️ Check your turbo’s part numbers
Before placing your order, Compare the part number on your turbocharger d’origin’ using the references given in this fact sheet. Having the same motor does not always guarantee compatibility.

If you are in any doubt, please contact us with the part number shown on your turbocharger and the exact vehicle details.
