This hybrid turbo for for the VAG 1.8T engine features da modification designed to adapt the dair flow of the compressor. Depending on the upgrade package chosen, it is fitted with a high-flow MFS compressor wheel, a 360° bearing stop and, for certain versions, a re-profiled intake casing d.
The documented applications include several A4 and A6 models Audi, as well as the Alhambra Seat, Volkswagen Passat B4 and Sharan with 1.8i engines.
This modification acts on the compressor wheel to d’adapt the compression capacity and the air flow rate d’air. The result depends on the engine’s configuration and the quality of its tuning.
The oversized impeller requires the intake casing to be re-profiled d. This combination aims to modify the compressor’s aerodynamic behaviour and its capacity to move air.
The documented specifications for for this variant include an MFS impeller oversized and a housing dwith a reprofiled inlet. The final power output depends on the settings and components associated with the engine.
A hybrid turbo retains a turbocharger architecture designed for to accommodate modified internal components. Depending on the specification, modifications may involve the compressor wheel, its dimensions, the geometry of the blades, the housings, the turbine wheel, the thrust bearing system or the balancing.
The aim is dto adapt the compression capacity and air flow rate d. However, a hybrid turbo is not defined solely by the appearance of its impeller: its overall geometry and the consistency of the modification determine its performance.
MFS stands for ‘Milled From Solid’, meaning a wheel machined from a solid block. This technology describes a manufacturing process and does not, on its own, guarantee an increase in air flow d.
A standard MFS impeller may retain a geometry similar to that of the original d. A Performance MFS impeller may adopt a geometry tailored to the modification, notably a different blade profile, height, width or diameter where such modifications are planned.
A standard MFS impeller can be just as glossy as an MFS impeller Performance. It is not its appearance that determines its performance, but its geometry and its ability to move more d’air. A higher airflow can contribute to power output with a suitably tuned engine, though this alone does not guarantee results.
The compressor impeller draws in and then compresses the air sent to the engine. Its diameter, profile, height, width and the arrangement of its blades influence the compressor’s aerodynamic behaviour.
dThe right geometry can move more air under certain conditions. The result also depends on the casings, the turbine wheel, the boost pressure and the engine tuning. A larger wheel therefore does not automatically guarantee better performance and may alter the response time.
The 360° thrust bearing, documented across the three stages, helps to distribute axial forces around the shaft. It does not, however, replace d’proper lubrication or d’correct installation.
Each specification listed undergo dhigh-speed balancing at 150,000 rpm on a Cimat VSR test bench. This process aims to minimise rotor vibrations and stresses, without compensating for inadequate lubrication, contamination or incorrect installation.
An adjustment to the engine management system is required for to make full use of the hybrid turbo’s characteristics. The mapping, boost pressure, fuel injection, exhaust and cooling systems must be checked or adjusted according to the configuration.
The wastegate must be adjusted when the ECU is remapped. The clutch, gearbox and other components under load must also be checked, depending on the vehicle and the level of tuning.
⚠️ WARNING — IMPORTANT BEFORE INSTALLATION
Identify and rectify the cause of the previous failure. Carefully check the lubrication circuit, the oil supply and return d, as well as the cleanliness of all pipes.
Check the inlet for foreign objects. Carry out priming in accordance with the applicable recommendations and follow the manufacturer’s instructions. The wastegate must be adjusted during ECU calibration.
A lubrication fault that is not rectified may lead to the turbocharger failing again.
Check the part number engraved or marked on the original turbo d, then compare it with the OEM and manufacturer part numbers in this data sheet.. Also check the make, model, generation, engine type, power output,Year and engine code where available.
An identical engine specification does not always guarantee compatibility, as there may be several different set-ups for for the same vehicle.
⚠️ Check your turbo’s part numbers
Before ordering, compare the part number marked on your original turbo d with the part numbers listed in this data sheet. An identical engine specification does not always guarantee compatibility.
If you have any doubts about fitting, please contact us with the full part number of your turbocharger.
Reference: AK03-004
Brand: ALFI TURBO ///
Year: September 1997 to March 2010, depending on the vehiclePower: 150 hpdisplacement: 1781 cm³Engine code: Not specifiedWarranty: 2 years
