Turbo Cartridge 3.0 TDI 163 190 204 211 218 224 249 258 272 374 hp, 059145873BJ, 059145873CH, 059145873DB, 059145873EN, 05914587

  • Online only
  • New product
New
Turbo Cartridge 3.0 TDI 163 190 204 211 218 224 249 258 272 374 hp, 059145873BJ, 059145873CH, 059145873DB, 059145873EN, 05914587
  • Turbo Cartridge 3.0 TDI 163 190 204 211 218 224 249 258 272 374 hp, 059145873BJ, 059145873CH, 059145873DB, 059145873EN, 05914587
ACG-687T
Cartridge turbo for, 3-., 0- TDI, 163, 190, 204, 211, 218, 224, 249, 258, 272 and 374 hp, depending on the application.. Compatible with engine codes CRTC, CSWB, CRTD, CRTE, CZVA, CRTF, CZVC, CZVF, CTCB, CZVD, CTCC, CZVB, CZVE, CZZA, CVMD, CVZA, DDXA, DDXB, DDXC, DDXD and DDXE. Warranty: 2 years.
Gasket Kit (Essential for Turbo Installation)
Gasket Kit (Essential for Turbo Installation)
12 €
Kit Montage CHRA, vis M5x8 5pcs, M6x10 5pcs, Rondelle diamètre 6 5pcs
Kit Montage CHRA, vis M5x8 5pcs, M6x10 5pcs, Rondelle diamètre 6 5pcs
9.9 €
€102.84 VAT included

85.7 tax excl.

Quantity
Delivered the next day (if ordered before 5 pm)

Description

This central cartridge Cartridge is intended for the documented applications 3.0 TDI Audi and Volkswagen, with power outputs ranging from 163 to 374 hp depending on the vehicle. Production periods range from May 2014 to May 2022, depending on the model and engine type.

OEM part numbers: 059145873BJ, 059145873BL, 059145873BP, 059145873CH, 059145873CL, 059145873DB, 059145873EN, 059145873ES and 059145873FA.
Manufacturer’s part numbers: 839078-0001, 839078-1, 839078-2001 and 839078-5001S.

Audi applications: A4 Allroad B9, A4 B9 saloon and Avant, A5 Coupé, Cabriolet and Sportback, A6 C7 saloon, Avant and Allroad, A7 Sportback, as well as the Q7 and Q7 Van. The documented versions produce 190, 211, 218, 249, 272 or 374 hp and, depending on their application, use the engine codes CRTC, CSWB, CRTD, CRTE, CZVA, CRTF, CZVC, CZVF, CTCB, CZVD, CTCC, CZVB, CZVE, CZZA, CVMD or CVZA.

Volkswagen applications: Amarok and Amarok Platform/Chassis fitted with the 3.0 TDI of 163, 204, 224 or 258 hp. The engine codes concerned are DDXA, DDXB, DDXC, DDXD and DDXE, for installations documented between June 2016 and May 2022, depending on the version.

Pre-installation advice: investigate the cause of the previous failure, check the oil supply and return d, clean the pipes and check that there are no foreign objects in the inlet. Prime the system in accordance with the applicable recommendations. Before ordering, compare the part number marked on the original turbo dwith the part numbers in this data sheet: an identical engine type does not always guarantee compatibility.

Product Details
ACG-687T
New
Attachments
Download

Turbo: specialists in turbochargers since 2012

ALFI TURBO specialises in the sale of turbochargers for for cars, commercial vehicles, heavy goods vehicles, construction machinery, agricultural machinery and boats: new turbochargers, remanufactured units, hybrid turbochargers, Cartridge and turbocharger spare parts. Over 20,000 items are available.

Find the right turbocharger for your engine

The turbocharger plays a vital role in the operation and performance d of a turbocharged engine. When a turbocharger needs replacing, it is important d to identify the exact part number before ordering.

ALFI TURBO supplies turbochargers for for a wide range of makes and engine types: cars, commercial vehicles, heavy goods vehicles, construction machinery, tractors and agricultural machinery, as well as various marine applications.

You can search for your turbo based on the vehicle or application, engine type, engine code, or directly using d an OEM or manufacturer part number found on your old turbocharger.

Turbo new, remanufactured, hybrid and Cartridge

Turbo new

Browse our range of new turbochargers for for diesel and petrol engines. ALFI TURBO has over 5,500 new turbochargers in stock for covering a wide range of makes, engine types and turbocharger part numbers.

View new turbochargers →

Turbo as remanufactured units

A standard exchange turbo allows you to replace a turbocharger whilst returning the old part where a deposit is required. Our catalogue includes numerous part numbers for from various makes and engine types.

View standard exchange turbochargers →

Hybrid Turbo

Hybrid turbos are designed for set-ups requiring greater air flow d and higher performance potential than a standard set-up. Specifications depend on the turbo, its tuning and the engine configuration.

View hybrid turbos →

Cartridge turbo

The turbo Cartridge, also known as the central turbo cartridge, comprises the main rotating components of the turbocharger. ALFI TURBO has over 6,000 Cartridge for turbo part numbers.

View turbo Cartridge →

for turbochargers for a wide range of applications

Our catalogue covers a wide range of d applications fitted with d a turbocharged engine.

  • diesel and petrolcars;
  • commercial vehicles;
  • heavy goods vehicles and lorries;
  • construction and civil engineeringmachinery;
  • tractors and agricultural machinery;
  • boats and marine applications.

How do you identify the correct turbo part number?

A single engine type may have been fitted with several different turbochargers depending on theYear, power output, engine version or technical evolution.. The application alone is therefore not always sufficient for to accurately identify the correct turbo.

Before ordering, note down the part numbers shown on the identification plate d of your old turbocharger. This may be d an OEM part number or d a part number from the turbo manufacturer.

Compare these part numbers with those listed on our product pages.. If in doubt, our team can help you verify the part number you are looking for before you place your order.

Turbo failure: identify the cause before replacement

A loss of power, an unusual whistling noise, oil consumption d, abnormal smoke or poor engine performance may be linked to a turbocharger fault.

However, a fault that appears to be turbo-related may also stem d from a lubrication issue, d from contaminated oil, d from a foreign object, from the intake or exhaust systems, or d from another engine peripheral component.

It is therefore important to investigate the cause of the fault before fitting a new turbo or a new Cartridge.

→ Identifying the symptoms d of a turbo failure

→ Understand the main causes of turbo failure d

ALFI TURBO, specialists in turbochargers since 2012

Since 2012, ALFI TURBO has been assisting private individuals and professionals in identifying and replacing turbochargers.

  • over 20,000 items in the catalogue;
  • over 5,500 new turbochargers in stock;
  • over 6,000 ‘ Cartridge ’ available;
  • new turbochargers, remanufactured units, hybrid units and Cartridge;
  • diesel and petrol engines;
  • a wide range of applications for road, agricultural, industrial and marine use;
  • fast delivery in France and across Europe;
  • warranty of up to 2 years depending on the product and applicable conditions.

BEFORE REPLACING A TURBO

A turbocharger failure may be the result d of another engine problem. Before fitting d a new turbo or Cartridge, identify and rectify the cause of the original fault to d avoid d damaging the new part.

Need d'help for finding your turbo?

Do you have a turbocharger part number but can’t find the matching part? Are you unsure which part number to choose? Send us the details from your old turbo so that our team can help you identify the part you’re looking for.

CONTACT ALFI TURBO
